Type Desktop sheet-fed scanner
Document Feeding Automatic or manual sheet feeding
Document size
Width 53 - 219mm (2.08 - 8.6in.)
Length 70 - 356mm (2.76 - 14in.)
Long Document Mode: up to 1,000mm (39.3in.)
Document thickness and weight
U-Turn path Automatic feeding: 0.06 - 0.15mm, 52 - 128g/m2 (14 - 32lb. bond)
Manual Feeding: 0.05 - 0.2mm, 42 - 157g/m2 (11 - 40lb. bond)
Straight path Automatic feeding: 0.06 - 0.15mm, 52 - 128g/m2 (14 - 32lb. bond)
Manual Feeding: 0.05 - 0.66mm, 42 - 546g/m2 (11 - 144lb. bond)
Business card size and thickness
Size 53.9 x 85.5mm (2.12 x 3.37in.)
Thickness 0.76 ± 0.08mm (0.03 ± 0.003in.)
Feeding Capacity 10mm stack or 100 sheets of 80g/m2 (20lb. bond)
Scanning Element 3-line CMOS CIS
Light Source LED (red, green, and blue)
Scanning Side Simplex / Duplex
Scanning Modes Black and White, Error Diffusion, High-Speed Text Enhancement, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level Grayscale, 24-bit Colour, Auto Colour Detection
Scanning Resolutions 100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi,
400 x 400dpi, 600 x 600dpi
Scanning speed (A4 / LTR, Portrait)
B&W 200dpi:  60ppm (Simplex), 120ipm (Duplex)
300dpi:  60ppm (Simplex), 120ipm (Duplex)
Grayscale 200dpi:  60ppm (Simplex), 120ipm (Duplex)
300dpi:  60ppm (Simplex), 120ipm (Duplex)
Colour 200dpi:  60ppm (Simplex), 120ipm (Duplex)
300dpi:  60ppm (Simplex), 84ipm (Duplex)
Interfaces SCSI-III / Hi-Speed USB 2.0
Scanner driver ISIS / TWAIN
Useful functions Job Function, Folio, Ultrasonic Double-Feed Detection, Rapid Recovery System, Moire Reduction, Prevent Bleed Through / Remove Background, Punch Hole Removal, Colour Dropout, Auto Page Size Detection, Text Orientation Recognition, Skip Blank Page, Deskew, MultiStreamTM, Prescan, User Preferences
Power requirements AC220 - 240V (50 / 60Hz)
Power Consumption 200V: 30W (Scanning), 2.2W (Sleep mode)
Operating Environment 10 - 32.5°C (50 - 90.5°F)
Humidity: 20 - 80% RH
Dimensions (W x D x H) Feed trays closed: 318 x 278 x 185.5mm (12.5 x 10.9 x 7.3in.)
Weight Approx. 6.5kg (14.3lb.)
Options / Consumables Barcode Module, Exchange Roller Kit

Specifications are subject to change without notice.

  1. Scanning speed may vary depending on PC environment, scanner settings, and other factors
